Electro-Voice ELX 112

Pasivna dvosistemska zvučna kutija 12" 250W

42.600,00

Specifikacije proizvoda:

  • Serija:
    • Live X
  • Frekventni odziv (-3dB):
    • 82 - 18K Hz
  • Frekventni opseg (-10dB):
    • 55 -20K Hz
  • Boja:
    • crna
  • Osetljivost:
    • 94 dB
  • Maksimalni SPL:
    • 132 dB
  • Pokrivanje H° x V°:
    • 90° x 50°
  • Kontinuirana snaga :
    • 250 W
  • Vršna (peak) snaga :
    • 1000 W
  • Visokotonac:
    • DH-1K
  • Niskotonac (bas):
    • 12"
  • Impedansa (oma):
    • 8 oma
  • Tip konektora:
    • NL4
  • Materijal:
    • Drvo - šperploča
  • Dimenzije Š x V x D:
    • 362 x 607 x 340 mm
  • Težina:
    • 16 kg

Opis proizvoda:

Designed for Pro Music, and other applications. 12” woofer and 1.5” high-frequency titanium compression driver 55 Hz – 20 kHz frequency range 94 dB SPL sensitivity; 132 dB max SPL 250 W continuous and 1000 W peak power handling Rugged wood cabinet — pole-mounts or stacks with Live X Subwoofers

Axial Sensitivity: 94 dB

Case Material: 9-ply, 15mm Plywood, Internally Braced, with Texured Paint

Frequency Response (-3 dB): 82 Hz - 18 kHz

Frequency Response (-10 dB): 55 Hz - 20 kHz

System Power Handling (continuous/program/peak):250/500/1000 Watts

Recommended High-Pass Frequency: 45 Hz

Max. SPL/1m (calc): 132 dB

Coverage (Nominal -6 dB) H°: 90 °

Coverage (Nominal -6 dB) V°: 50 °

LF Transducer: (1) EVS-12K, 305mm (12”) Woofer

HF Transducer: DH-1K, 39mm (1.5”) Titanium Diaphragm Compression Driver

Crossover Frequency: 2.1 k Hz

Nominal Impedance (Passive): 8 Ω

Minimum Impedance: 7 Ω

Connector Type: Dual NL4

Grill: 18GA Steel with Black Powdercoat

Height: 607 mm (23.9")

Width: 362 mm (14.25")

Depth: 340 mm (13.39")

Weight Net: 15.8 kg
