DAP GIG-123 V2
DAP GIG-123 V2
DAP GIG-123 V2
DAP GIG-123 V2
DAP GIG-123 V2
DAP GIG-123 V2
DAP GIG-123 V2
DAP GIG-123 V2

Kod proizvoda:1958

DAP GIG-123 V2

Audio mikser, 6 mic/line + 3 stereo kanala, D2403

52.600,00

Dostupnost proizvoda: Ima na lageru

Specifikacije proizvoda:

Opis proizvoda:

Mono Inputs 6
Mono Input Connector 3-pin XLR, TRS balanced 6.3 mm
Mono Input Gain Range 60 dB
Mono Input Impedance 3000 Ω
Stereo Inputs 3
Stereo Input Connector TRS balanced 6.3 mm
Stereo Input Gain Range 20 dB
Stereo Input Impedance 10000 Ω
Auxiliary Inputs 1
Auxiliary Input Connector TRS balanced 3.5 mm
Auxiliary Input Impedance 10000 Ω
FX Return Inputs 1
FX Return Connector TRS balanced 6.3 mm

Outputs
Main Outputs 1
Main Output Connector 3-pin XLR, TRS balanced 6.3 mm
Main Output Maximum Level 22 dBu
Main Output Impedance 100 Ω
Auxiliary Outputs 1
Auxiliary Output Connector TRS balanced 6.3 mm
Auxiliary Output Impedance 120 Ω
Group Outputs 2
Group Output Connector TS unbalanced 6.3 mm
Group Output Impedance 120 Ω
FX Send Outputs 1
FX Send Connector TRS balanced 6.3 mm
FX Send Impedance 120 Ω
Control Room Output 1
Control Room Output Connector TRS balanced 6.3 mm
Control Room Output Impedance 120 Ω
Headphone Output 1
Headphone Output Connector TRS balanced 6.3 mm
Headphone Output Impedance 32 Ω

Digital Playback
Audio Interface Yes
Audio Interface USB Input 1
Audio Interface Input Connection USB-C
Audio Interface Supported Input Channels 2
Audio Interface Supported Output Channels 2

Extension Module
Media Player Yes
Audio Module Supported Files MP3, WAV, WMA
Audio Module Maximum Storage Size 64 GB
Audio Module Media In/Out USB-A
Audio Module USB Type 2.0

Audio Specifications
THD Level % < 0.2 %
Signal-to-noise Ratio > 108 dB
Crosstalk -86 dBu
Frequency Response Minimum 20 Hz
Frequency Response Maximum 22000 Hz
Phantom Power 48 V

Sound Editing
Dynamics Processing Compressor
Built-in FX Yes
FX Types Chorus, Delay, Echo, Flanger, Hall , Phaser, Plate, Reverb, Room, Tremolo

Wireless Specifications
BT Yes
BT Version 5.0
BT Range 20 m (65.617 ft)
Control and Programming
Display 7-segment

Electrical Specifications and Connections
Power Supply 100-240 V AC 50/60 Hz
Output voltage 15 V DC
Power Consumption 13 W
Power Connector In Low Voltage DC plug

Power Adapter
Adapter type AC-DC adapter
Input voltage 100-240 V AC, 50/60 Hz
Output voltage 15 V DC
Output current DC (mA) 1000 mA

Mechanical Specifications
Fader Length 70 mm (2.756″)
Height (mm) 75 mm (2.953″)
Width (mm) 400 mm (15.748″)
Length (mm) 367 mm (14.449″)
Installation Depth (Excl. Connector) 75 mm (2.953″)
Flightcase Size Optional 19''
Rack Units 9 U
Housing Metal
Colour Black
Weight 4.04 kg (8.907 lb)
IP Rating IP20 (indoor use only)

Product Properties
LED Indicators +48V, BT Pairing, Clip, Output level, Power
Handles All sides

Included Items
Included Accessories Adapter



Prikazi više
