Dynacord Cobra Top

Trosistemska zvučna kutija


Specifikacije proizvoda:

Opis proizvoda:

DYNACORD´s COBRA-TOP is a 3-Way cabinet for use in compact line arrays and other demanding applications where wide horizontal coverage, extremely low distortion and a low sensitivity against acoustic feedback are mandatory.


The mid-range of the COBRA-TOP uses selected DYNACORD C8 cone transducers in a line array configuration. The C8 transducers show significantly lower distortion than typical horn/compression driver combinations. Therefore an extremely natural sound quality over large distances can be achieved. For the high frequencies of the COBRA-TOP an Electro-Voice DH2T titanium diaphragm driver and a HPT94 constant directivity horn are used in order to prevent any set-up and adjustment problems for the main direction and the near field. The DYNACORD COBRA-TOP uses a dual vented direct-radiator design equipped with an Electro-Voice EVX 155 for the low frequencies. For Near-Fill and Side-Fill applications and for the reinforcement of speech the COBRA-TOP cabinets can be used fullrange without any problems.


The cabinet is equipped with an electronic circuit called VOICE COIL TRACKING PROTECTION. This circuit senses the terminal voltage of the transducers and simulates the thermal behaviour of the transducer voice coils. In case of potential thermal overload the power applied to the speakers is reduced to a safe level. Power amps up to 1200W/8Ohms can be used in order to have maximum dynamic range without the danger of thermal overload in non-controlled situations. The VOICE COIL TRACKING PROTECTION exhibits “soft” switching characteristics, so no annoying clicks or pops are audible. The circuitry automatically resets after the voice coil temperatures have reached a safe value.



Cabinet MID - HIGH Cabinet

Cabinet type Passive 3-way

Impedance 8 Ohms

Rated power RMS 600 W

Program power 1200 W

SPL 1W / 1m 100 dB

Max. SPL 1m 131 dB

Frequency range ( -10dB ) 50Hz - 15kHz

Disp. Angle 1 kHz -6dB H 120° x V 30°

Disp. Angle 10kHz -6dB H 90° x V 40°

Int. Passive Crossover 700Hz - 4kHz

Rec. Active Crossover 124Hz

Voice coil tracking protection LOW - MID - HIGH

Components HIGH DH 2T / HPT 94

Order No. 355 391 / 357 979

Components MID C8 Line array

Order No. 4x 361 376

Components LOW EVX 155

Order No. 359 561

Connectors FR 4-pole 1+/1-

Connectors LO - MID - HIGH 4-pole 2+/2- (SYSTEM)

Connections Speakon 2x NL4 MPR

Dimensions mm (WxHxD) 600 x 495 x 717

Shipping weight 65 kg

Weight 60 kg

Cabinet 18mm

Style Birch plywood

Outfit Black

Coating Polyurethane

Steel grille Powder coated

Handles 2 pcs.

Ancra Tracks 4 pcs.

Webbing strap point 2 pcs.

Front cover 1 pcs.

Castors 4x 100mm

Warranty 36 Month
