The EVID Compact Sound speaker series continues the EVID family’s focus on form and function, with stylish, architecture-friendly design, a best-in-class performance-to-size ratio, and user-friendly installation and operation. The system is designed to provide exceptional background/foreground audio performance in retail spaces, restaurants, and similar environments – all while being heard but hardly seen. In addition to EV-engineered components for superior quality and reliability, the system features quick-access connections, simple wiring, and flexible mounting options (hardware provided), and is compatible with a variety of existing EV amplifier products, making it a great choice for contractors and end-users alike. Available in black or white finish.
|
Bracket Adjustment Range |
EVID 2.1: 160° x 60° ; EVID 40S: Fixed |
|
Coverage, Music |
EVID 2.1: 100° x 100°; EVID 40S: Omnidirectional |
|
Coverage, Voice |
EVID 2.1: 150° x 150°; EVID 40S: Omnidirectional |
|
Impedance |
EVID 2.1: 16 ohms; EVID 40S: Dual 8 ohm / mono 4 Ω |
|
Included Accessories |
Wall bracket; hex wrench |
|
Maximum SPL |
EVID 2.1: 100 dB; EVID 40S: 114 dB |
|
Power Handling (Continuous / Peak) |
EVID 2.1: 30 W; EVID 40S: 200 W |
|
Transducer |
EVID 2.1: 50 mm (1.97 in); EVID 40S: 200 mm (0") |
|
Transformer Taps (Transformer Version Only) |
EVID 2.1: NA; EVID 40S: 100 W, 50 W, 25 |
|
Frequency Response (-10 dB) |
EVID 2.1: 180 Hz - 20 kHz; EVID 40S: 180 Hz - 20 k Hz |
|
Sensitivity 1 W/1 m |
EVID 2.1: 84 dB; EVID 40S: 88 dB |
|
Connector Type |
Phoenix (2-pin) |
|
Enclosure Material |
EVID 2.1: ABS (fire rated); EVID 40S: Wood (MDF); |
|
Height |
EVID 2.1: 115mm; EVID 40S: 400 mm (0") |
|
Width |
EVID 2.1: 85mm; EVID 40S: 400 mm (0") |
|
Depth |
EVID 2.1: 95mm; EVID 40S: 230 mm (0") |
|
Weight Net |
0 oz (0 g) |
|
Shipping Weight |
35.27 oz (1000 g) |
