DAP DRX 10
DAP DRX 10
DAP DRX 10
DAP DRX 10

Kod proizvoda:1497

DAP DRX 10

Pasivna dvosistemska zvučna kutija 10" 120 W D3631

39.000,00

Specifikacije proizvoda:

  • Frekventni opseg (-10dB):
    • 55 -20K Hz
  • Boja:
    • crna
  • Osetljivost:
    • 95 dB
  • Maksimalni SPL:
    • 118 dB
  • Pokrivanje H° x V°:
    • 50° x 50°
  • Kontinuirana snaga :
    • 120 W
  • Vršna (peak) snaga :
    • 240 W
  • Niskotonac (bas):
    • 10"
  • Impedansa (oma):
    • 8 oma
  • Tip konektora:
    • NL4
  • Materijal:
    • Drvo - šperploča
  • Dimenzije Š x V x D:
    • 328 x 550 x 320 mm
  • Težina:
    • 13 kg

Opis proizvoda:

• 240 Watt
• Lightweight: 13 kg
• Reinforced cabinet
• High driver protection



Specifications

System Type: 2-Way Vented Passive Speaker cabinet
Continuous Power: 120 Watts
Peak Power: 240 Watts
Horn Coverage: 50°H x 50°V
Speaker Sensitivity (1W.1m): 95 dB SPL ±3dB
Max. SPL: 118dB at 1m
Frequency Response: 58Hz~20kHz (- 6dB)
Impedance: 8Ω
Crossover Frequency: 3.2KHz
Protection: High Frequency Protection
Woofer: 10" / 2" Voice Coil
Driver: 1" / 1" Voice Coil
Construction: 15mm plywood, glued and reinforced
Paint: Black, scratch resistant
Pole-mount: ABS 35mm pole-mount
Connectors: 2 x SPK4
Dimensions (HxWxD): 550 x 328 x 320 mm
Weight: 13 kg
