Coverage (Nominal -6 dB) |
Omnidirectional in normal operating range |
|
Environmental Specs |
Standard versions: IEC 60529 IP44. PI and FG versions: IEC 60529 IP55 |
|
Input Connections |
Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover |
|
Internal Passive Low-Pass Filter |
100 Hz 12 dB per octave |
|
Frequency Response (-3 dB) |
67 - 95 Hz |
|
Frequency Response (-10 dB) |
46 - 124 Hz |
|
Recommended High-Pass Frequency |
35 Hz |
|
Sensitivity 1 W/1 m |
103 dB |
|
Max. SPL/1m (calc) |
135 dB |
|
System Power Handling (Continuous/Program/Peak) |
400, 800, 1600 Watts |
|
LF Transducer |
EVS15SB, 15 in (381mm) Driver |
|
Nominal Impedance (Passive) |
Passive: 4, Biamp: 8 Ω |
|
Minimum Impedance |
Passive: 3.4, Biamp: 6.4 Ω |
|
Enclosure Material |
13-ply weather-resistant birch |
|
Grill |
Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind. PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind |
|
Suspension |
(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included) |
|
Height |
768.6 mm (30.26") |
|
Width |
470 mm (18.5") |
|
Depth |
467 mm (18.39") |
|
Weight Net |
28.4 kg (62.61 lbs) |
