The DAP PA-530TU is a compact 30Watt, 100V mixer amplifier with 4 selectable sources and 2 microphone inputs. Both microphone inputs are equipped with phantom power and can also be selected as line input. An integrated speech filter can be applied to improve the audibility. It has one dedicated line input on the backside and a special easy access line/phone front input to connect mp3 players or mobile devices. It has a built-in USB audio player and tuner with a large LCD display which shows the active source, tuner information and ID3 tags. The built-in FM tuner can store 10 presets. The PA-530TU is an all-in-one compact 100V solution for small installations.
These amplifiers are designed for PA systems with applications such as announcement, intercommunication, background music and broadcasting in convention-halls, shopping centers, dining rooms, auditoriums and recreation areas. These desk top amplifiers have an integrated protective circuit to withstand overload or short-circuits of output. This results in very high reliability and easy installations without extra audio processors. It is a complete range from simple amplifiers till matrix amplifiers with built-in tuner and media player.
Specifications
Outputs
Power: 30W
Zones: 1
100V & 8Ohm: Terminals
Line output: XLR
Loop through: RCA
Headphones: 6,3mm Jack
Inputs
2x Mic/Line: XLR/Jack combi & Terminals
1x Line: RCA
Front input: 3,5mm Jack
Media player
Source: USB type A
Supported files: MP3, Wav
Format: FAT32 up to 32Gb
Playback: Program, Repeat, Continuous
Tuner
FM band: 87,5 – 108 MHz
Presets: 10
Antenna: 75Ohm
Features
Speech filter: -3dB, 300Hz 6db/oct
Phantom power: 18V
Tone Control: Bass 100 Hz, treble 12 KHz, +/-12dB
General
Power supply: 230V AC
Back-up power supply: DC 24V
Power consumption: 80W
Power connection: IEC
Dimensions: 270x262x88mm (WxDxH)
Weight: 6 Kg
