Electro-Voice ELX 200-12P
Electro-Voice ELX 200-12P
Electro-Voice ELX 200-12P
Electro-Voice ELX 200-12P
Electro-Voice ELX 200-12P
Electro-Voice ELX 200-12P

Kod proizvoda:1922

Electro-Voice ELX 200-12P

Aktivna dvosistemska zvučna kutija 12"

102.000,00 72.500,00

Dostupnost proizvoda: Ima na lageru

Specifikacije proizvoda:

  • Serija:
    • ELX 200
  • Frekventni odziv (-3dB):
    • 57 - 16K Hz
  • Frekventni opseg (-10dB):
    • 51 – 20K Hz
  • Snaga pojačala:
    • 1200 W
  • Boja:
    • crna
  • Maksimalni SPL:
    • 130 dB
  • Pokrivanje H° x V°:
    • 90° x 60°
  • Visokotonac:
    • DH-1C 1-inch titanium
  • Niskotonac (bas):
    • 12"
  • Materijal:
    • Polipropilen (plastika)
  • Dimenzije Š x V x D:
    • 363 x 629 x 344 mm
  • Težina:
    • 15,6 kg

Opis proizvoda:

12-Inch 2-Way Powered Speaker



Available Color Black
Connector Type (1) Stereo RCA Input, (2) XLR/TRS combo jack, and (1) XLR
Coverage (Nominal -6 dB) H 90°
Coverage (Nominal -6 dB) V 60°
Crossover Frequency 1700Hz
Depth 344mm (13.54")
Enclosure Material Polypropylene Composite
Family ELX200
Frequency Range (-10 dB) 51 Hz – 20 kHz
Frequency Response (-3 dB) 57 Hz – 16 kHz
Grill 18 AWG steel with powdercoat
Height 629mm (24.76")
HF Transducer DH-1C 1-inch titanium compression driver
LF Transducer EVS-12M 300 mm (12 in)
Max. SPL/1m (calc) 130dB
Power Consumption 100 - 240 V~, 50 - 60 Hz, 1.8A
Power Rating 1200W
Powered or Passive Powered
Shipping Weight 17.7kg (39.02 lbs)
Speaker Type Full-Range
Suspension (3) M10 suspension points
Weight Net 15.6kg (34.39 lbs)
Width 363mm (14.29")
Woofer Size 12inch
