Enclosure Material |
15 mm plywood with EVCoat |
|
Family |
ELX200 |
|
Frequency Range (-10 dB) |
41 Hz – 165 Hz |
|
Frequency Response (-3 dB) |
49 Hz – 135Hz |
|
Grill |
18 AWG steel with powdercoat |
|
Height |
397mm (15.63") |
|
LF Transducer |
EVS-12L 300 mm (12 in) |
|
Low Pass Frequency |
Adjustable: 80 Hz, 100 Hz, 120Hz, 150 Hz |
|
Max. SPL/1m (calc) |
129dB |
|
Power Consumption |
100 - 240 V~, 50 - 60 Hz, 1.8A |
|
Power Rating |
1200W |
|
Powered or Passive |
Powered |
|
Shipping Weight |
22.3kg (49.16 lbs) |
|
Speaker Type |
Subwoofer |
|
Weight Net |
19.1kg (42.11 lbs) |
|
Width |
445mm (17.52") |
|
Woofer Size |
12inch |
