Enclosure Material |
15 mm plywood with EVCoat |
|
Family |
ELX200 |
|
Frequency Range (-10 dB) |
40 Hz – 145 Hz |
|
Frequency Response (-3 dB) |
47 Hz – 105Hz |
|
Grill |
18 AWG steel with powdercoat |
|
Height |
600mm (23.62") |
|
LF Transducer |
EVS-18L 457 mm (18 in) |
|
Low Pass Frequency |
Adjustable: 80 Hz, 100 Hz, 120 Hz, 150 Hz |
|
Max. SPL/1m (calc) |
132dB |
|
Power Consumption |
100 - 240 V~, 50 - 60 Hz, 1.8A |
|
Power Rating |
1200W |
|
Powered or Passive |
Powered |
|
Shipping Weight |
33.1kg (72.97 lbs) |
|
Speaker Type |
Subwoofer |
|
Weight Net |
29kg (63.93 lbs) |
|
Width |
507mm (19.96") |
|
Woofer Size |
18inch |
