Electro-Voice R300-HD
Electro-Voice R300-HD

Kod proizvoda:537

Electro-Voice R300-HD

Bežični mikrofon sa dinamičkom glavom Electro-Voice PL 22, 618 - 634 MHz, 10 mW, 16 frekvencija


Dostupnost proizvoda: Ima na lageru

Specifikacije proizvoda:

Opis proizvoda:

The HT-300 metal handheld transmitter is made to withstand the rigors of daily use but still be comfortable in your hand. The PL22 dynamic microphone is the perfect all-around microphone for speaking engagements, singing and emcees. The cardioid pick up pattern rejects noise from the surroundings, helps to control audio feedback, and still allows an experienced vocalist to work the microphone. The receiver for the R300 system is equally at home on a table top or in a 19 inch equipment rack. Rack mount kits and front mount antenna cables are available for the R300 for a professional installation. For applications with up to 4 receivers in one rack, the APD4+ antenna splitter can provide antenna and power feeds.

Antennas: Flexible TNC 1/2 Wave

Audio Frequency Response: 80 Hz - 18kHz +/- 2dB

Battery Life: 14 hours with (2) AA alkalines typical

Case Material: Metal

Connector Type: 1/4 inch unbalanced, 3-pin XLR balanced

Controls: on/off, Set, Up, Down, Sync

Distortion (@ 1 kHz, 40 kHz deviation): less than 1.0, 0.4 typical %

Diversity: True Antenna

Dynamic Range: greater than 95 dB

Element: PL22 Cardioid Dynamic

Power Supply: 12 VDC, 500mA max

Receiver Type: Synthesized PLL Agile UHF

RF Frequency Range: 16 MHz

RF Output: 8 mW typical

RF Sensitivity (12 dB SINAD): less than 1.0 uV

Signal-to-Noise Ratio (A-weighted): greater than 100 dB

Squelch: Tone code plus Amplitude
