Electro-Voice Zx 5
Electro-Voice Zx 5

Kod proizvoda:630

Electro-Voice Zx 5

Pasivna dvosistemska zvučna kutija 15" 600W

144.000,00

Dostupnost proizvoda: Ima na lageru

Specifikacije proizvoda:

  • Serija:
    • Zx
  • Frekventni odziv (-3dB):
    • 58 - 18K Hz
  • Frekventni opseg (-10dB):
    • 39 - 20K Hz
  • Boja:
    • crna
  • Osetljivost:
    • 98 dB
  • Maksimalni SPL:
    • 132 dB
  • Pokrivanje H° x V°:
    • 90/60° x 50/60°
  • Kontinuirana snaga :
    • 600 W
  • Vršna (peak) snaga :
    • 2400 W
  • Visokotonac:
    • Electro-Voice ND2
  • Niskotonac (bas):
    • 15"
  • Impedansa (oma):
    • 8 oma
  • Tip konektora:
    • NL4
  • Materijal:
    • Polipropilen (plastika)
  • Dimenzije Š x V x D:
    • 692 x 446 x 411 mm
  • Težina:
    • 22 kg

Opis proizvoda:

Dvosistemska zvučna kutija Zx5-90 15" 600W,8 oma



The Electro-Voice® Zx5 is a 15-inch, two-way cabinet with the most elegant, high-impact, composite enclosure, featuring the newest generation of EV components: the all-new DXV3150 500-watt, 15-inch woofer and the all-new, two-inch neodymium ND2 compression driver.



The Zx5 is rated for 600-watt, long-term power handling and is able to produce high SPLs while providing a very smooth frequency response. With two available coverage patterns (60 degree x 60 degree or 90 degree x 50 degree), two adjustable monitor angles (45 degrees or 55 degrees) and ten built-in rigging and suspension points allow for a variety of mounting accessories, the Zx5 fits a variety of applications such as installations of individual speakers or clusters in entertainment, houses-of-worship, as well as on stage with bands, musicians, and PA rental companies.





Chassis Size 381 mm (15")
Color Black, white
Input Connections Parallel Neutrik® NL4
Speaker Type Full-range, Mid-High, Two-Way, Wedges
Frequency Response (-3 dB) 58 - 18000 Hz
Frequency Response (-10 dB) 39 - 20000 Hz
Internal Crossover Switchable biamp or passive crossover
Recommended High-Pass Frequency 36 Hz
Sensitivity 1 W/1 m 98 dB
Max. SPL/1m (calc) 132 dB
Coverage (Nominal -6 dB) H 90/60 °
Coverage (Nominal -6 dB) V 50/60 °
System Power Handling (Continuous/Program/Peak) 600//2400 Watts
LF Transducer 15-inch DVX3150A
LF Power Handling 500 Watts
HF Power Handling 40 Watts
LF Nominal Impedance 8 Ω
HF Transducer 2-inch ND2
HF Nominal Impedance 8 Ω
Crossover Frequency 1500 Hz
Nominal Impedance (Passive) 8 Ω
Minimum Impedance 6.5 Ω
Enclosure Material High Impact Polystyrene
Flying Yes
Outdoor Yes
Grill Polyester Powder Coated, 18GA Galvanized Steel
Height 692 mm (27.24")
Width 446 mm (17.56")
Depth 411 mm (16.18")
Weight Net 22.2 kg (48.94 lbs)
