Kod proizvoda:661

Electro-Voice EVA-2082S/1220

Electro-Voice EVA-2082S/1220 - Pasivna zvučna kutija

Pozovite za cenu

Specifikacije proizvoda:

Opis proizvoda:

Dosistemska Line array zvučna kutija EVA-2082S/1220 2x8" 350W

Each EVA module is available with either a 90° or 120° horizontal dispersion pattern and is acoustically designed to work with any otherEVA module.



Two versions are available with 6° vertical dispersion patterns (for longthrow), and may be combined for use as the main building blocks of a typical line array: 2082S/126 (120° x 6°) and 2082S/906 (90° x 6°).



Mixed-model array configurations allow EVA to precisely address a wide variety of venues, e.g. EVA-2082S/906 for long-throw with EVA- 2082S/920 for near-field coverage. A combination of these modules provides optimum vertical coverage for any application.



Two versions are available with 20° vertical dispersion patterns (for nearfield coverage): 2082S/1220 (120° x 20°) and 2082S/920 (90° x 20°).





Freq. Response1 (-3 dB): 60 Hz - 19 kHz

Freq. Range1 (-10 dB): 45 Hz - 20 kHz

Rec. Hipass Frequency: 50 Hz

Axial Sensitivity2: 104 dB (1W/1m)

Max. Calculated SPL2: 129 dB Continuous, 135 dB Peak

Horizontal Coverage: 120°

Vertical Coverage: 20°

Power Handling: 350W Continuous, 1400W Peak

LF Transducer: (2) EVS2008, 8 in (203mm) Driver

HF Transducer: (4) DH2005, 1.25 in (32mm) Diaphragm Compression Driver

Crossover Frequency: 1740 Hz

Nominal Impedance: 16 Ohms

Minimum Impedance: 12 Ohms

Connectors: (2) 4 Contact 10 AWG Phoenix/EuroBlock Style Screw Terminals PI Version - Gland Nut with Included Input Panel Cover

Enclosure Material: Plywood and MDF with EVCoatTM

Grille: 16 GA Galvanneal, Powdercoated PI Version - Stainless Steel with Hydrophobic Cloth

Suspension: EVA Grid (Sold Separately)

Dimensions (H x W x D): 20.17” x 23.50” x 14.53” (512.2mm x 596.9mm x 369.1mm)

Net Weight: 81.0 lbs (36.8 kg)

Shipping Weight: 91.0 lbs (41.3 kg)





Prikazi više
