Channels (Mono + Stereo): 6 + 4
Auxiliaries (MON, FX, AUX): 2 Pre, 2 Post, 2 Pre/Post switchable
Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel
into 2.66 Ohms: 2 x 1350 W
into 4 Ohms: 2 x 1000 W
into 8 Ohms: 2 x 600 W
Rated Output Power, THD=0.1%, Single Channel
into 4 Ohms: 2 x 900 W
into 8 Ohms: 2 x 450 W
Maximum Output Voltage of power amplifier, no load: 74 Vrms
THD at 1kHz, MBW=80kHz
MIC input to Master A L/R output, +16 dBu, typical: < 0.005%
POWER AMP INPUTS to Speaker L/R output: < 0.075%
DIM 30, power amplifier, 60Hz, 7kHz: < 0.05%
IMD-SMPTE, power amplifier, 60Hz, 7 kHz: < 0.015%
CMRR, MIC input, 1 kHz: > 80 dB
Equivalent Input Noise, MIC Input, A-weighted, 150 &ohm: -130 dBu
Signal/Noise-Ratio, power amplifier, A-weighted, 4 Ohms: 105 dB
Output Stage Topology, amplifier: Class D
Equalization
LO Shelving: +/- 15 dB / 60 Hz
MID Peaking, mono inputs: +/- 15 dB / 100 Hz .. 8 kHz
MID Peaking, stereo inputs: +/- 12 dB / 2.4 kHz
HI Shelving: +/- 15 dB / 12 kHz
Master EQ, 11-band (63, 125, 250, 400, 1k, 1.6k, 2.5k, 4k, 6.3k, 12k Hz): +/- 10 dB / Q = 1.5-2.5
Filter
LO-CUT, mono inputs: f=80 Hz, 18 dB/oct
VOICE FILTER, mono inputs
FEEDBACK FILTER, MON1/2: 70 Hz .. 7 kHz, Notch, -9 dB
Speaker Processing: LPN, switchable
Display: High Contrast OLED
Effects: Dual stereo 24/48-bit multi effects processors
Effects presets: 100 Factory + 20 User, Tap-Delay
Remote control: Footswitch, MIDI
Digital Audio Interface
Channels: 4 In / 4 Out
AD/DA Conversion: 24bit
Sampling Rate: 44.1 / 48 / 88.2 /96 kHz
PC Interface: USB 2.0, Female Type B
MIDI Interface: 5-pin DIN connector, In / Out
Output Power Control: Adjustale RMS Limiter
Protections
Mixer Outputs (Relay controlled): MON1, MON2, MASTER A
Amplifier: Audio Limiters, High Temperature, DC, HF, Short Circuit, Peak Current Limiters, Turn-On-Delay
Switching Mode Power Supply (µPC controlled): Inrush Current Limiters, Mains Over/Under Voltage, Mains Over Current, High Temperature
Cooling: Continuous speed controlled Fans
Phantom Power, switchable in groups: 48V DC
Power Requirements (SMPS with auto range mains input): 100 V .. 240 V AC, 50 Hz .. 60 Hz
Power Consumption, at 1/8 maximum output power, 4 Ohms: 450 W
Safety Class: 1
Ambient Temperature Limits: +5 °C .. + 40 °C / 40 °F .. 105 °F
Dimensions (W x H x D), mm
Rack-Mount: 483 x 135 x 443.7
with lid: 510.5 x 164.5 x 498.5
Weight
Net weight, without lid: 12.5 kg
Net Weight, with lid: 14.0 kg
Shipping Weight: 17.0 kg
Optional Accessories
RMK-1000-3 (Rack-Mount Kit): F01U161506 (DC-RMK1000-3)
Gooseneck Lamp, 12V/5W, 12", XLR 4 pol: F01U118983 (DC-LITLITE-4P)
FS11 (Footswitch with LED): F01U100598 (DC-FS11)
* U cenu sistema nisu uračunati stalci i kablovi.
